Waterjet Cutting Machine

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1468375

• Place of Origin:

  China
• X-aixs:3000mm
  Y-axis:1500mm
  Z-axis:200mm
  Waterjet Cutting Platform
  -Structure: Bridge
  -Max. Traverse speed: 10m/min
  -Cutting Precision: 0.1mm , Repeat positioning precision: 0.02mm
  -stainless steel body and material holding bars.
  -Full iron structure guarantee stable body of whole platform and motion system
  -Adjustable material holding bar for large material.
  -Imported zero clearance ball crew and line rail imported from Taiwan.
  -Taiwan made/ YASKAWA/SIEMENS AC servo (Ac Motor)
  -Auto concentrate lubricating system.

  -Abrasive tank capacity: 10KG
  -Automatic water draining system.
  -Air-control hi-pressure valve system.
  UHP SYSTEM
  - Max. Pressure: 380Mpa
  - Main motor: 50HP/37KW
  - Power supply: 380V/50Hz
  - Hi-pressure Intensifier : U.S JET made
  - Electronic Valve: U.S SUNNY.
  - Intelligent variable stroke hydraulic pump.
  - Manual-adjust pressure valve for different situation .
  - Imported "GL" and circulating water cooling system.
  - Water pump made in Italy.
  - High capacity hi-pressure water reservoir made of imported stainless steel.
  - Siemens PLC
  - Over heat protecting system
  Waterjet cutting head
  - Air-control hi-water valve
  - Abrasive Waterjet nozzle: ROCTEC brand
  - Waterjet cutting head -Orifice: 0.17mm /0.25mm/0.30mm/0.33mm/0.36mm
